Silicon Lab Equipment

Picture of the ultra-clean class-1000 clean-room area
Wafer handling
OLYMPUS DSX110 microscope
Probe System Cascade Microtech CM300; up to 12 inches wafers, 14 nm technology node
A wafer of the ams-h350 H35DEMO chip for the ATLAS experiment probed in the Cascade Microtech station
The first prototype (1.5x1.0 mm2) of the IHP chip for the TT-PET project probed in the Cascade Microtech station
The first prototype (1.5x1.0mm2) of the IHP chip for the TT-PET project probed in the Cascade Microtech station
Plasma cleaning system
Plasma cleaning system
SET Accµra100 flip-chip machine
SET Accµra100 flip-chip machine glue dispenser
Mitutoyo metrology system (1600 x 900 x 600): mechanical + optical probes
Wire bonding machine Hess&Knipps B810
Pull tester Royce 650
Wire bonded ams-ah18 ATLASPix1 monolithic chip for the ATLAS experiment
